Raspberry Pi, Arduino, and Electronics PCB Ruler V3.0

$17.00

$17.00

the 12″ Raspberry Pi, Arduino, and Electronics PCB Ruler version 3.0 from Kickstarter. In case you missed it, you can get yours here!

SKU: N/A Category:

Description

A revamped 12″ Printed Circuit Board Ruler. In case you missed the Kickstarter, you can get yours here!



An all new 12″ PCB ruler featuring the Raspberry PI 4 GPIO pin out, Raspberry Pi Pico pin out, Arduino pin outs, and commonly used through hole electronic components all on one easy to use reference.

Here’s what’s on the ruler:

Front Side

Click images to enlarge.

Pin outs of a few commonly used micro controllers and, of course, a ruler.

  • The Raspberry PI 4 GPIO
  • The Raspberry PI Pico
  • Arduino Micro
  • Arduino Nano
  • Teensy 4.0
  • Graduations in centimeters and inches
  • Half of the inch graduations are sixteenths and half are tenths.
  • The tenths graduations are also numbered from 0 to 9



Back Side

Click Images to enlarge

An assortment of commonly used electronics references.

  • Logic gate symbols and truth tables
  • Seven segment LED display lettering
  • Resistor color code and common resistor size footprints
  • Capacitor code
  • LED schematic symbol, pin out, and through hole footprints
  • Tactile push button switch footprints
  • Transistor schematic symbols, pin outs, and footprints
  • 78XX voltage regulator pin outs
  • Diode schematic symbol, pin out and an assortment of commonly used diodes
  • Ohm’s law
  • Font height in mm and Mils
  • Wire size
  • PCB trace widths and ampacities
